Model

AUV-1600

Printing Method

Piezo Ink-jet Method

Printing Width

210-1610mm

Ink Cartridge

Type

UV Ink

Capacity

440ml Refill Cartridge

Color

Double 4-color（C M Y K）or 8-color（C M Y K +LC LM OR GR）

Capacity

Continuous Ink Supply Cartridge

Max Printing Resolution

1440 dpi ×1440 dpi

Media Control

Automatic Feeding System and Sheet Cutter

Height of Printing Heads

Two types optional :1.2mm/2.8mm

Printing Heads Cleaning

Automatic cleaning and manual cleaning

Interface

USB2.0/ HIUSB

Power Consumption

During Operation

1.7A/ 100V to 240V±10%,50/ 60 Hz

Sleep Mode

0.5A/ 100V to 240V±10%,50/ 60 Hz

Power-saving Function

Automatic Sleep Feature

Acoustic Noise Level

Printing Mode

≤65 dB (according to ISO 7779)

Standby Mode

≤40 dB (according to ISO 7779)

Printer Dimensions (with stand)

2500mm(W)x740mm(D)x1240mm(H)

Weight (with stand)

148kg

Power consumption

Under 1500VA

Environmental

Power On

Temperature: 20 to 32°C Humidity: 35 to 80%RH (non-condensing)

Power Off

Temperature: 5 to 40°C Humidity: 20 to 80%RH (non-condensing)
